Becker GK615

Description

BECKER presents – according to its tradition for light-weight and also efficient and sturdy avionics-the BECKER GK 615, a mobile VHF-Transceiver with the AR 6201. The GK 615 is the ideal small portable basestation – because of its compact size, its sturdiness and its great efficiency – for use on small airfield, in balloons or in vehicles. Based on modern technology in the production (SMD) we reached optimal performance concentrated in a small unit.

The BECKER AR 6201 has an output of 5 – 7 Watts (16 W PEP) and offers 760 channels can easily programmed and recalled. The BECKER GK 615 has panellighting and automatic test routine as standard functions. The large, clear and dazzle-free LCD display shows the active frequency and either the standby frequency, memory channel, outsidetemperature or supply-voltage. The nicely shaped and study aluminium case integrates a dry-lead-acid battery (12V 2,2Ah) which can be easily charged via a socket located on the front panel.

This integrated charging circuit allows the operation from 10 to 32 V. The basic equipment includes: dynamic hand microphone (1PM415-1), dry-lead-acid battery, charging device, antenna, carrying belt, handle and carrying bag and also a vehicle mounting device. That means that the unit is complete and operational as soon as it is delivered.

Specifications

• 118.000 MHz – 136.975 MHz
• 25 kHz/8.33 kHz channel spacing
• 760/2280 channels
• Carrier power nominal ?5 W, (RF Output power depends on the charging status of the battery)
• Sunlight readable full graphic LCD-display
• Channel mode, memory up to 99 channels
• Dual watch mode
• -20°C to +55°C
• Ext. supply voltage: 10.0 V DC – 32.0 V DC
• Power consumption: standby < 80 mA, transmit mode: 2.5 A
• Lead-acid-dry battery 2 Ah
• Battery charger
• AC-connector cable
• Whip antenna
• Carrying case
• Dynamic hand microphone, 1PM415-1
• Certification:EASA 210.1294 (AR6201-())
