Aveo Samson JP

Hi-Performance Landing & Taxi Light
  • These NEW Aveo landing and taxi lights combine high intensity and affordability
  • Choose from 6 anodized finishes to enhance your paint scheme
  • Available with either landing or taxi lenses, optimized for superior illumination
  • “Drop In” upgrade for legacy lights
  • Simple installation
  • High performance
  • PAR 46

Description

  • These NEW Aveo landing and taxi lights combine high intensity and affordability
  • Choose from 6 anodized finishes to enhance your paint scheme
  • Available with either landing or taxi lenses, optimized for superior illumination
  • “Drop In” upgrade for legacy lights
  • Simple installation
  • High performance
  • PAR 46

    Specification

    Dimensions (mm): 137.9 mm x 46.1 mm
    Dimensions (inches): 5.429“ x 1.816“
    Operating Voltage Range: 9 – 32 V DC
    Input Current (at 25°C): 4.5 A @14V
    2.3 A @28V
    Output Power: 54 W
    Ambient Temperature: from -55°C to +85°C
    from -67°F to +185°F
    Transient Voltage: 80 V max
    Over-Voltage Lockout: +33VDC, not less
    Intensity (Landing):
    Intensity (Taxi):
    255.000 cd
    27.500 cd
    Landing Lens Angle:
    Taxi Lens:
    8° Landing
    28° Taxi
    Reverse Polarity Protection: Yes
    Overheat Protection: Yes (temperature dependent decrement of intensity, see note below)
    Waterproof, Dust-proof, Vibration-proof: Yes
    Useful Life: not less than 30,000 aircraft flight hours



Additional information

Weight 0.03 kg
Dimensions 18 × 8 × 8 cm
