Description
- These NEW Aveo landing and taxi lights combine high intensity and affordability
- Choose from 6 anodized finishes to enhance your paint scheme
- Available with either landing or taxi lenses, optimized for superior illumination
- “Drop In” upgrade for legacy lights
- Simple installation
- High performance
- PAR 3
Specification
Dimensions (mm): 111.5 mm x 44 mm Dimensions (inches): 4.39“ x 1.73“ Operating Voltage Range: 9 – 32 V DC Input Current (at 25°C): 4.5 A @14V
2.3 A @28VOutput Power: 54 W Ambient Temperature: from -55°C to +85°C
from -67°F to +185°FTransient Voltage: 100 V max Over-Voltage Lockout: +32VDC, not less Intensity (Landing):
Intensity (Taxi):100,000 cd
51,000 cdLanding Lens Angle:
Taxi Lens:8° Landing
9° x 20° TaxiReverse Polarity Protection: Yes Overheat Protection: Yes (temperature dependent decrement of intensity, see note below) Waterproof, Dust-proof, Vibration-proof: Yes Useful Life: not less than 30,000 aircraft flight hours
